Combo Belts

Tight radius belt with very high belt pull capacity

Siegling Prolink Combo belts combine the
strength of the tried-and-tested series 5 ST with
the small and innovative curve radius of series 11.

S11/S5 ST-45 GRT CCW

S11/S5 ST-45 GRT CCW

Open (45 %) lattice-shaped surface
counterclockwise belt travel

Belt types*

MaterialsPPPOM-CRPA
ColorsWT/BLWT/BLBL
Open area [%]454545
Allowable belt pull [N/mm (lb/ft)](Straight)18 (1233)25 (1713)20 (1370)
Allowable belt pull [N (lb)](Curves)1200 (270)2100 (473)1680 (378)
Weight [kg/m2 (lb/ft2)]10.2 (2.1)13.2 (2.7)12.2 (2.5)


*Side flexing, pitch 25 mm (1")

WT = White
BL = Blue

S5 ST/S11-45 GRT CW

S5 ST/S11-45 GRT CW

Open (45 %) lattice-shaped surface clockwise belt travel

Belt types*

MaterialsPPPOM-CRPA
ColorsWT/BLWT/BLBL
Open area [%]454545
Allowable belt pull [N/mm (lb/ft)](Straight)18 (1233)25 (1713)20 (1370)
Allowable belt pull [N (lb)](Curves)1200 (270)2100 (473)1680 (378)
Weight [kg/m2 (lb/ft2)]10.2 (2.1)13.2 (2.7) 12.2 (2.5)


*Side flexing, pitch 25 mm (1")

WT = White
BL = Blue
